| 1 | Tube Cutting Length | — | 6000–12000 mm | — | — |
| 2 | Tube Unloading Length | 6000 mm | 9000 mm | 12000 mm | — |
| 3 | Round Tube Diameter Range | Ø50–Ø360 mm (Bevel: >Ø80) | — | — | National standard tube |
| 4 | Square Tube Side Length Range | 50–360 mm (Bevel: >80) | — | — | National standard tube |
| 5 | X/Y Axis Positioning Accuracy | ±0.1/1000 mm | — | — | — |
| 6 | X/Y Axis Repeat Positioning Accuracy | ±0.1 mm | — | — | — |
| 7 | Maximum Feeding Speed | 60 m/min | — | — | Processing speed and idle stroke parameters decrease as tube weight increases |
| 8 | Maximum Chuck Rotation Speed | 60 r/min | — | — | — |
| 9 | Maximum Acceleration | 0.6 G | — | — | — |
| 10 | Minimum Clamping Wall Thickness | ≥2 mm | — | — | — |
| 11 | Cutting Head Swivel Angle | 0°/±45° (optional) | — | — | SENFENG (Optional beveling) |
| 12 | Tail Stock Length | 0 mm | — | — | Achievable with reasonable nesting layout |
| 13 | Dimension (L×W×H) | 21500×5600×2450 mm | 24500×5600×2450 mm | 27500×5600×2450 mm | Subject to actual delivery |
| 14 | Total Machine Weight | 19700 kg | 21800 kg | 23700 kg | Subject to actual delivery |
| 15 | Maximum Chuck Load | 1000 kg | — | — | Tube Weight: ≤83.3 kg/m |
| 16 | Phase | Three-phase | — | — | — |
| 17 | Rated Voltage | 380 V | — | — | — |
| 18 | Frequency | 50 Hz | — | — | — |
| 19 | Total Power Protection Level | IP54 | — | — | — |
