Product Description
The MAX QBH I 12.9x9.4 (1.5KW) is a compact and high-performance laser processing head designed for industrial laser cutting and material processing applications. Manufactured by MAX, it is designed to support laser systems with power ratings of up to 1500W (1.5KW), providing reliable and efficient laser beam transmission. With a 12.9 mm diameter and 9.4 mm height, its compact construction allows convenient integration into compatible laser processing equipment. The laser head is suitable for applications requiring accurate, stable, and consistent laser processing performance.
Key Features
Brand: MAX
Model: QBH I 12.9x9.4
Maximum Power: 1500W (1.5KW)
Diameter: 12.9 mm
Height: 9.4 mm
Compact and space-saving design
Designed for high-precision laser processing
Suitable for industrial laser cutting systems
Supports efficient laser beam transmission
Suitable for integration into compatible laser equipment
Designed for stable and consistent operation
Suitable for continuous industrial applications when operated within specified parameters
Applicability
The MAX QBH I 12.9x9.4 is suitable for laser cutting, metal processing, fabrication, and other industrial laser applications using compatible laser sources. It can be applied in the processing of materials such as mild steel, stainless steel, aluminium, and other metals, depending on the laser source, optics, machine configuration, and material thickness.
It is particularly suitable for:
CNC laser cutting machines
Sheet-metal processing equipment
Metal fabrication machinery
Industrial laser cutting systems
Automated laser processing equipment
General-purpose 1.5KW laser applications
Compatibility
The MAX QBH I 12.9x9.4 should be installed only in laser systems that support the corresponding QBH interface, optical configuration, and power rating. Compatibility should be checked with the existing laser source, fibre connector, focusing optics, nozzle assembly, cooling arrangement, and mounting configuration before installation.
For replacement applications, the interface dimensions, optical specifications, mounting arrangement, and laser power requirements should be matched with the original laser head. Using a compatible configuration helps ensure proper beam transmission, stable operation, and reliable cutting performance.
Advantages
The compact dimensions make the MAX QBH I 12.9x9.4 suitable for equipment where installation space is limited. Its 1.5KW power capability provides an effective solution for a range of industrial cutting and material-processing requirements. When correctly matched with the laser source and optical system, it can provide precise, consistent, and reliable processing performance.
Technical Specifications
| Specification | Details |
|---|
| Brand | MAX |
| Model | QBH I 12.9x9.4 |
| Power Rating | 1500W / 1.5KW |
| Diameter | 12.9 mm |
| Height | 9.4 mm |
| Application | Laser Cutting & Material Processing |
| Interface | QBH |
| Design | Compact Industrial Laser Head |
| Suitable Systems | Compatible 1.5KW Laser Systems |
